ZB114KQE-TFD-551 Scroll Refrigeration Medium Temp Compressor
Contact us for more information
ZB114KQE-TFD-551 Scroll Refrigeration Medium Temp Compressor
Product number:
RBD8408
| Product Group : | ZB Copeland Scroll Compressor Ranges for Medium Temperature Refrigeration |
|---|
General Information
| Product Group : | ZB Copeland Scroll Compressor Ranges for Medium Temperature Refrigeration |
|---|---|
| Model Number : | ZB114KQE-TFD-551 |
| Type : | Scroll Compressor |
| VSD Capable : | Yes |
Compressor
| Displacement : | 43.4 m³/h |
|---|
Connections
| Discharge Connection Pipe Size : | 1 1/4 in |
|---|---|
| Discharge Line Connection : | 22.22 mm |
| Suction Connection Pipe Size : | 1 3/4 in |
| Suction Line Connection : | 35 mm |
Electrical
| IP Class : | IP21 |
|---|---|
| LRA : | 174 A |
| MOC : | 27.9 A |
| Voltage : | 380-420/3/50 V/Ph/Hz |
Measurements
| Height : | 573 mm |
|---|---|
| Length : | 264 mm |
| Net Weight : | 63 kg |
| Weight : | 65 kg |
| Width : | 285 mm |
Motor
| Motor Type : | DOL |
|---|
Oil
| Oil : | POE RL32-3MAF |
|---|---|
| Oil Charge : | 3250 cc |
| Oil Type : | POE 32 |
Performance
| Nominal HP : | 15.5 HP |
|---|
R134A Performances
| R134a Nominal Capacity -5°C : | 16300 W |
|---|
R404A Performances
| R404A Nominal Capacity -5°C : | 30300 W |
|---|
Refrigerant
| Refrigerant : | R134a, R404A, R507 |
|---|
