SUH13BITS Sinclair Terrel Inverter 13000 BTU R32 Silver H/Wall Split
Contact us for more information
SUH13BITS Sinclair Terrel Inverter 13000 BTU R32 Silver H/Wall Split
Product number:
SUH13BITS
| Product Group : | Sinclair |
|---|
General Information
| Product Group : | Sinclair |
|---|---|
| Model Number : | SUH13BITS |
Cooling Capacity
| Cooling Capacity : | 3.5 kW |
|---|
Electrical
| Power Supply : | 220-240/1/50 V/Ph/Hz |
|---|
Heating Capacity
| Heating Capacity : | 3.8 kW |
|---|
Indoor Unit Attributes
| Depth (IU) : | 212 mm |
|---|---|
| Height (IU) : | 294 mm |
| Net Weight (IU) : | 11 kg |
| Width (IU) : | 889 mm |
Logistical Information
| Gross Weight : | 13 kg |
|---|---|
| Packaging Height : | 365 mm |
| Packaging Width : | 940 mm |
Pipes
| Max Piping Length : | 15 m |
|---|---|
| Min Piping Length : | 3 m |
Refrigerant
| Refrigerant : | R32 |
|---|---|
| Refrigerant Charge : | 0.57 kg |
Sound Power/Pressure
| Sound Pressure Level : | 42 dB(A) |
|---|
Temperature
| Temperature Range Cooling : | -15 ~ 50 °C |
|---|---|
| Temperature Range Heating : | - 25 ~ 30 °C |
| File name | Extension | Size |
|---|---|---|
| Owners Manual | 7.3 MB | |
| Installation Manual | 2.95 MB | |
| Brochures | 1.6 MB |
Set Component Parts
SIH13BITS Sinclair Terrel Inverter 13000 BTU R32 Silver Indoor
SIH13BITS Sinclair Terrel Inverter 13000 BTU R32 Silver Indoor
SOH13BIT Sinclair Terrel Inverter 13000 BTU R32 Outdoor
SOH13BIT Sinclair Terrel Inverter 13000 BTU R32 Outdoor
