Description
AKS 4100 Level Sensor Cable 5m w HMI
Contact us for more information
Liquid level sensor, AKS 4100, Cable version
Danfoss
Product number:
RDN2029
| Product Group : | Danfoss Sensors |
|---|
General Information
| Product Group : | Danfoss Sensors |
|---|
Additional Info
| Family : | AKS 4100 |
|---|
Cable
| Insertion Length : | 197.00 in, 5000 mm |
|---|
Connections
| Connection Size : | 1 in |
|---|---|
| Connection Type : | G |
Electrical
| IP Class : | IP67 |
|---|---|
| Max Load Resistance : | 500 Ohm |
| Power Consumption : | 0.7 W |
Inputs/Outputs
| Output Signal Range : | 4-20 mA |
|---|
Logistical Information
| Commodity Code : | 90261029 |
|---|---|
| Country Of Origin : | FRA |
| EAN : | 5702428414906 |
| Gross Weight : | 3.682 kg |
Measurements
| Weight : | 2.77 kg |
|---|
Pressure
| Max Operating Pressure : | 100.0 Bar |
|---|
Refrigerant
| Refrigerant : | R22, R134a, R401A, R402A, R404A, R407A, R407B, R407C, R407F, R409A, R410A, R421A, R502, R507A, R717 |
|---|
Standards
| Approval : | CE, EAC, GOST, LLC CDC TYSK, UKCA |
|---|
Temperature
| Ambient Temperature Range : | -40-80 °C |
|---|---|
| Temperature Range : | -60-100 °C |
Valves
| Design : | Cable version |
|---|
| File name | Extension | Size |
|---|---|---|
| Installation Manual | 17.24 MB | |
| Conformity Declaration | 203.04 KB | |
| Conformity Declaration | 488.98 KB | |
| Brochures | 601.5 KB | |
| Technical Literature | 2.74 MB |
