Description
Compressor Scroll SY300A4CBI Stub Tube
Contact us for more information
Compressor Scroll SY300A4CBI Stub Tube
Product number:
RDM6250
| Product Group : | Danfoss Scroll for Air Conditioning |
|---|
General Information
| Product Group : | Danfoss Scroll for Air Conditioning |
|---|---|
| Colour : | Blue |
| Model Number : | SY300A4CBI |
| Type : | SY300A4CBI |
Capacity
| Capacity Control : | Fixed speed |
|---|
Compressor
| Power Supply Compressor : | 400/3/50 460/3/60 V/Ph/Hz |
|---|---|
| Swept Volume : | 437.50 cm³ |
| Technique : | Scroll |
Connections
| Connection Type : | Brazed |
|---|---|
| Discharge Connection Height : | 665 mm |
| Discharge Connection Pipe Size : | 1 1/8 in |
| Discharge Connection Size : | 1 1/8 in |
| Suction Connection Height : | 196 mm |
| Suction Connection Pipe Size : | 1 5/8 in |
| Suction Connection Size : | 1 5/8 in |
Electrical
| Frequency : | 50/60 Hz |
|---|---|
| IP Class : | IP54 |
| LRA : | 270 A |
| MCC : | 69 A |
| Power Supply : | 400/3/50 V/Ph/Hz |
| RLA : | 49.3 A |
Logistical Information
| Commodity Code : | 84143081 |
|---|---|
| Country Of Origin : | FRA |
| EAN : | 5702428660648 |
| Gross Weight : | 162.38 kg |
Measurements
| Diameter : | 344 mm |
|---|---|
| Height : | 738 mm |
| Weight : | 157.15 kg |
Oil
| Oil Charge : | 8 L |
|---|
Pipes
| Pipe Diameter : | 1 1/8 in |
|---|
Refrigerant
| Max Refrigerant Charge : | 20 kg |
|---|---|
| Refrigerant : | R22, R134a, R407C, R513A |
