ASV-25BSI Sinclair Caravan Unit 9000BTU Indoor - R32
Contact us for more information
ASV-25BSI Sinclair Caravan Unit 9000BTU Indoor- R32
Product number:
ASV-25BSI
| Product Group : | Caravan Units |
|---|
General Information
| Product Group : | Caravan Units |
|---|---|
| Model Number : | 053401000016005 |
Air Volume/Air Flow
| Air Flow (Low/Medium/High) : | 200/250/330 m³/h |
|---|
Cooling Capacity
| Cooling Capacity : | 2.6 kW |
|---|
Electrical
| Current (Cooling) : | 4.7 A |
|---|---|
| Current (Heating) : | 4.2 A |
| Input (Cooling) : | 1.2 kW |
| Input (Heating) : | 1.0 kW |
| Power Supply : | 220-240/1/50 V/Ph/Hz |
Energy Efficiency/Performance
| COP : | 2.2 |
|---|---|
| EER : | 2.3 |
Heating Capacity
| Heating Capacity : | 2.4 kW |
|---|
Indoor Unit Attributes
| Depth (IU) : | 610 mm |
|---|---|
| Height (IU) : | 49 mm |
| Weight (IU) : | 2.7 kg |
| Width (IU) : | 458 mm |
Logistical Information
| Gross Weight : | 4.0 kg |
|---|---|
| Packaging Height : | 112 mm |
| Packaging Length : | 678 mm |
| Packaging Width : | 550 mm |
Mounting
| Mounting Details : | 400 X 400 mm |
|---|
Refrigerant
| Refrigerant : | R32 |
|---|---|
| Refrigerant Charge : | 0.47 kg |
Sound Power/Pressure
| Sound Power Level : | 63 dB(A) |
|---|---|
| Sound Pressure Level : | 53 dB(A) |
Temperature
| Outdoor Operating Temp. Range (Cooling) : | 18 ~ 46 °C |
|---|---|
| Outdoor Operating Temp. Range (Heating) : | - 5 ~ 24 °C |
